IH1-天空六号

High-strength aluminium-magnesium alloy casting shell, small size and light weight.

Highly integrated controller

Ergonomic side outlet installation design, more convenient for installation and maintenance.

Parameter

Rated Power
250W

Max Speed
25km/h

Max Torque
8.5N.m
See more
Consult now >
  • Model Name
  • IH1
  • Type
  • Frame Integrated
  • Pack Construction
  • 70（10S7P) (18650Cells)
  • 6S（13S5P) (18650Cells)
  • Rated Voltage
  • 36V
  • 48V
  • Rated Capacity
  • 10.5Ah / 14Ah / 17.5Ah / 24.5Ah
  • 8.8Ah / 10.4Ah / 11.6Ah / 14Ah 17.5Ah
  • Energy Content Approx
  • 387Wh / 504Wh / 630Wh / 882Wh
  • 422Wh / 499Wh / 556Wh /672Wh /840Wh
  • Pack Construction
  • 40（10S4P) (21700Cells)
  • 39（13S3P) (21700Cells)
  • BMS
  • Smart / Standard
  • Communication Protocol
  • CAN / 485 / UART / LIN
  • Certifcation
  • EN 15194:2017 / UN38.3 / ISO13849 / CE / ROHS
  • BatteryDimension (L*W*H)
  • 375mm × 75mm ×90 mm
  • Weight
  • ＜3.5kg
  • Water Proof
  • >IP65
